The Tier 3/Stage IIIA QSM11 engine is one of the Quantum Series of rail engines from Cummins with innovative technology that delivers more for less.

  • QSM11-C335 CM876 CPL5412

  • Cummins

  • 1-7 days

  • Genuine Original package or Ne

  • 1 years

Availability:
Quantity:
Inquire Add to Basket

PDF Export

Small Tips for Quick Service:

If you need assistance with selecting the right replacement parts for your engine, please contact our ONLINE SERVICE to get fast customer support.


For us to provide you with the correct information, please have your Cummins Engine Part Number or Engine Serial Number ready, so that we can give you the best price possible along with our expertise.


Cummins QSM11 Engine Overview

No
Item
Data
1
Engine Model
QSM11-C335 CM876 CPL5412
2
Displacement
10.8L
3
Cylinder
6 cylinders
4
Valve
16 valves
5
Cold Style
Water- cooled
6
Start
Electric Start
7
Powder Range
74HP - 140HP 55KW- 104KW
8
Torque Range
210LB-FT - 398LB-FT
9
Emission Standard
Euro 4


CONFIGURATIONS AND MODEL NAMES
EPA Model NameNot Available
Marketing Engine Configuration #D353020CC06
Marketing Model NameQSM11
Service Model NameQSM11 CM876 M101
Technical Engine Configuration #D353020CX03
ENGINE BUILD DETAILS
Build Date2021-06-22T00:00:00Z
Build PlantJEP - JAMESTOWN
CPL #5412
Shop OrderSO20133
Warranty Start DateNot Available
TECHNICAL SPECIFICATION DETAILS
ECM CodeBA20084
Fuel Pump Part #Not Available
Fuel Pump CalibrationXP85


QSM for Rail

The Tier 3/Stage IIIA QSM11 engine is one of the Quantum Series of rail engines from Cummins with innovative technology that delivers more for less.


The QSM11 has more power, more torque and higher durability – all while achieving lower fuel consumption, lower emissions and less servicing. Using the Cummins PowerMatch tool set, it is possible to custom-tailor the engine torque curves and calibration features to the specific operation of the equipment. This means higher productivity and fuel efficiency benefits for the rail operator.

The QSM11 has been designed with features which include:

• Tier 3/Stage IIIA emissions capability
• increased durability and reliability
• lower total life costs of ownership
• high power and torque


The QSM11 is designed to provide the operator superior value and reliability, while meeting stringent worldwide emissions standards.


Additional ratings may be available.  Check with Qingbang Online Service.


Cummins QSM11 Engine Ratings

QSM11 CPL No.

Rated Powder/ Speed (HP@RPM)

Torque

(LB-FT@RPM)

Usage

CPL 2828

315@1800

1160@1400

ATRICULATED DUMP TRUCK TA25 TA27 TA30 TR35


CONTAINER HANDLER B917 C222 G117


CRANE TFC45


EXCAVATOR R450LC-7A R450LC-9 R485LC R520LVS HX480S R455SH


FRONT END LOADER HL780-7


REAR DUMP TRUCK 7540K


SCOOPTRAM COPCO ST14


TELETRAM UNDERGROUND DUMP TRUCK

COPCO MT436


HAUL TRUCK ADT 30


LOADER FRONT END LOADER  921C


COMBINE HARVESTER ROCK CRUSHER AF7


SNOW PLOW PORT TECH PV350 PV400 PV446


EXCAVATOR WHEEL LOADER CLG888H CLG890H CLG950E


EXCAVATOR LG6490E


EXCAVATOR FR480E


TRACTOR AG


YARD TRACTOR R382


DRILL, EXCAVATOR,  LOADER XE470D XE490D XR290 LW800K


DRILL ZR360

CPL 2828

315@2100

1180@1400

CPL 2828

320@2000

1260@1400

CPL 2828

335@1800

1255@1400

CPL 2828

335@2000

1320@1400

CPL 2828

335@2100

1255@1400

CPL 2829

350@2000

1380@1400

CPL 2829

350@2100

1310@1400

CPL 2829

360@1800

1260@1400

CPL 2829

360@2100

1350@1400

CPL 2829

375@2000

1400@1400

CPL 2829

375@2100

1400@1400

CPL 2829

385@1800

1400@1400

CPL 2829

400@1800

1400@1400

CPL 2829

400@2100

1400@1400

CPL 2829

415@2100

1400@2743

CPL 8471

335@2000

1320@1400

CPL 8471

375@2000

1400@1400

CPL 8471

375@2100

1400@1400

CPL 8471

400@2000

1400@1400

CPL 8471

400@2100

1400@1400

CPL 8608

290@2100

1090@1400

CPL 8608

300@2000

1162@1400

CPL 8608

310@2100

1161@1400

CPL 8608

335@2100

1235@1400

CPL 8545

300@2100

1050@1400

CPL 8545

330@2100

1235@1400

CPL 8545

335@2100

1235@1400
