QSC8.3 series Industrial engine is a 6-cylinders in line, 8.3 liter four-strokes engine with 114 mm bore and 135 mm stroke. DCEC QSC8.3 series Industrial engine equipped with Equipped with Electrically Control High-pressure Common Rail. The prime power range of is 152 HP to 260 HP.
If you need assistance with selecting the right replacement parts for your engine, please contact our ONLINE SERVICE to get fast customer support.
For us to provide you with the correct information, please have your Cummins Engine Part Number or Engine Serial Number ready, so that we can give you the best price possible along with our expertise.
Cummins QSC8.3 Engine Overview
No
Item
Data
1
Engine Model
Construction Machinery Engine QSC8.3 CM850 QSC New Condition Diesel Engine Power 8.3L 260HP
2
Displacement
8.3L
3
Cylinder
6 cylinders
4
Cooling Method
Water- cooled
5
Rated Power
260 Bhp @ 2200 Rpm
6
Torque Peak
870 Ft Lb @ 1500 Rpm
7
Emission Standard
Tier 3 and Stage IIIA
8
Governed Power
260 Bhp @ 2200 Rpm
CONFIGURATIONS AND MODEL NAMES
EPA Model Name
Not Available
Marketing Engine Configuration #
D413075CC03
Marketing Model Name
QSC
Service Model Name
QSC8.3 CM850(CM2850)
Technical Engine Configuration #
D413075CX03
ENGINE BUILD DETAILS
Build Date
2023-03-10T00:00:00Z
Build Plant
DAR - DARLINGTON
CPL #
4891
Shop Order
SO35310
Warranty Start Date
Not Available
TECHNICAL SPECIFICATION DETAILS
ECM Code
W91378
Fuel Pump Part #
Not Available
Fuel Pump Calibration
R541
DCEC QSC8.3 Industrial Engine
DCEC QSC8.3 series Industrial engine is a 6-cylinders in line, 8.3 liter four-strokes engine with 114 mm bore and 135 mm stroke. DCEC QSC8.3 series Industrial engine equipped with Equipped with Electrically Control High-pressure Common Rail. The prime power range of is 152 HP to 260 HP.
To achieve different output, DCEC QSC8.3 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support. DCEC QSC8.3 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC QSC8.3 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information. If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
