Cummins QSK50 Engine Overivew
Configurations and Model Names
EPA Model Name
Not Available
Marketing Engine Configuration #
D283038CX03
Marketing Model Name
QSKTAA50-C
Service Model Name
QSK50 CM2150 MCRS
Technical Engine Configuration #
D283038CX03
Engine Build Details
Build Date
2025-04-19T00:00:00Z
Build Plant
CQP - CHINA - CHONGQING (CCEC)
CPL #
3728
Shop Order
SO61177
Warranty Start Date
Not Available
Technical Specification Details
ECM Code
AQ60443
Fuel Pump Part #
Not Available
Fuel Pump Calibration
9999
QSK50 FOR WELL SERVICING (TIER 4 FINAL)
Outwork. Outrun. Outperform.
In demanding oil and gas applications, dependability is everything. That’s where the superior uptime and productivity of the Tier 4 Final QSK50 make the difference. Its V16 configuration offers up to 2500 hp (1864 kW) – an excellent choice for tough fracing jobs.
Outwork.
The Cummins QSK50 for Tier 4 Final is built upon the reliable, dependable Tier 2 engine, with minimal base engine changes, giving the customer greater reliability and durability compared to other Tier 4 Final solutions. Heat-rejection levels are similar to those of the Tier 2 engine as well, so there is no need to re-engineer the cooling package. Not only is the cooling package the same at Tier 2, but the Cummins QSK50 for Tier 4 Final drop-in design replaces the engine and muffler in your equipment, minimizing complexity and simplifying maintenance, and reduces noise on the job site.
Outrun.
The QSK50 for Tier 4 Final was built upon the proven Tier 2 platform, with some enhancements. Advanced combustion technology is applied to the QSK50, allowing the engine to run more efficiently. Coupled with the addition of improved crankcase breather, customers can expect an increase in 10% life to overhaul.
Outperform.
The Cummins SCR Exhaust Aftertreatment system allows the engine to run efficiently and generates low particulate, while increasing fuel efficiency over Tier 2. You can expect the same power and performance, in a cleaner, quieter package.
Engine Type
60° vee, 16-cylinder
Displacement
3,066.4 cu in
50.25 liters
Bore and stroke
6.25 in x 6.25 in
159 mm x 159 mm
Oil system capacity
216 US qt
204 liters
Coolant capacity
180 US qt
170 liters
Aspiration
Single-stage Turbocharged Aftercooled
Two-stage Turbocharged Aftercooled and Intercooled
Length
112 in (2,844.8 mm)
105 in (2,667 mm)
Width
61 in (1,549.4 mm)
73 (1,854.2 mm)
Height
71 (1,803.4 mm)
74 in (1,879.6 mm)
Dry Weight
13,822 lb (6,270 kg)
12,698 lb (5,760 kg)
Wet Weight
14,808 lb (6,717 kg)
13,590 lb (6,164 kg)
Additional ratings may be available. Check with Qingbang.
Cummins QSK50 FOR WELL SERVICING (TIER 4 FINAL) Engine Ratings
