| Reference Number | Part Number | Description |
| 1 | 3375467 | Locator Pin (for Pots) |
| 2 | 3375468 | Fuel Filter (Tank) |
| N/A | 3376989 | Adapter (Spin On Filter) |
| 3 | 3375469 | Drive Belt |
| 4 | 3375470 | High Pressure Inline Filter |
| 6 | 3375479 | Temp/Metering Control (Printed Circuit Board) |
| 6 | 3377228 | Rebuilt Temp/Metering Control Board |
| 7 | 3375480 | Fuse (1 Amp) |
| 8 | 3375481 | Fuse (5 Amp) |
| 9 | 3375482 | Link, 1 ring (3/8 PTB/PTC) |
| 9 | 3375483 | Link, 2 ring (3/8 PTB/PTC) |
| 9 | 3375484 | Link, 3 ring (3/8 PTB/PTC) |
| 9 | 3375485 | Link, 4 ring (5/16 PTB/PTC) |
| 9 | 3375487 | Link, 6 ring (H/NH/J-C) |
| 9 | 3375488 | Link, 7 ring (3/8 PTD) |
| 9 | 3375489 | Link, 8 ring (5/16 PTD) |
| 9 | 3375490 | Link, 9 ring (K-PTD) |
| 9 | 3376308 | Link, 11 ring (High Feed Port, Flanged PTD) |
| 9 | 3376309 | Link, 10 ring (3/8 PTD Flanged) |
| 10 | 4918929 | Rotary Control Valve PTFE Face |
| 11 | 3375638 | Metering Switch (Orange) |
| 12 | 3375639 | Main Drive On Switch Fuel System (Green) |
| 13 | 3375640 | Main Drive Stop Switch (Red) |
| 14 | 3375642 | Heat Sink Assembly |
| 15 | 3375642 | Cam (Std. PTD (.189 lift)) |
| 15 | 3375645 | Cam (K-PTD (.310 lift)) |
| 15 | 3376169 | Cam (Small Cam Top Stop (.169 lift)) |
| 15 | 3376170 | Cam (Big Cam Top Stop (.230 lift)) |
| 16 | 3375643 | Adapter Pot (3/8 PTD) |
| 16 | 3823838 | Adapter Pot (3/8 PTD Top Stop) |
| 16 | 3375646 | Adapter Pot (K PTD) |
| 16 | 3375648 | Adapter Pot (5/16 PTB/PTC) |
| 16 | 3375649 | Adapter Pot (3/8 PTB/PTC) |
| 16 | 3823233 | Adapter Pot (L10) |
| 16 | 3376862 | Adapter Pot (K STC) |
| 17 | 3375651 | Plug, Clamp Cylinder and Pressure Block |
| 18 | 3375652 | Cylinder Slide Ring (Clamp Cylinder) |
| 19 | 3375653 | Gasket (Clamp Cylinder) |
| 20 | 3375654 | O'ring (Gaco) |
| 21 | 3375655 | Packing Seal (Gaco) |
| 22 | 3375656 | Packing Seal (Gaco) |
| 23 | 3375657 | Glyd Ring (Clamp Cylinder Seal) |
| 24 | 3165098 | Digital Indicator Gauge Kit |
| 25 | 3375663 | Nylon Washer, Fuel Arm |
| 26 | 3375665 | Lower Oil Seal, Cam Box |
| 27 | 3375666 | Lower Gasket, Cam Box |
| 28 | 3375667 | Upper Gasket, Cam Box |
| 29 | 3375668 | Gasket, Tappet Housing |
| 30 | 3375670 | O-ring, Cam Box Cover |
| 31 | 3375674 | Cam Drive Key |
| 32 | 3375676 | Datum Valve Assembly |
| 33 | 3375679 | Thermistor, Fuel Tank |
| 34 | 3375680 | Heater, Fuel Tank |
| 35 | 3375682 | Transducer Cable Assembly (for Magnetic Pick Up) |
| 36 | 3375683 | Transducer Cable Assembly (for Fuel Arm) |
| 37 | 3376314 | Nylon Driven Gear, Stirrer |
| 37 | 3376316 | Steel Drive Gear, Stirrer |
| 38 | 3375751 | Roller Bearing, Datum Valve Lever |
| 39 | 3375752 | Tapered Bearing, Camshaft |
| 40 | 3375754 | Tank Thermostat |
| 41 | 3375755 | Switch (Float Tank, Mod. D) |
| 42 | 3375756 | Contactor (208/240 V. 60 Hz. Mod. D) |
| 42 | 3375926 | Contactor (208/240 V. 60 Hz. Mod. C Stands) |
| 43 | 3375757 | Overload, 5.5 - 8 Amp, OL1 Mod. D Stands |
| 43 | 3375927 | Overload, 6 - 9 Amp, OL1 Mod. C Stands |
| 43 | 3376310 | Overload, 10 - 13 Amp, Mod. D heavy duty |
| 46 | 3376174 | Overload, 4 - 6 Amp Mod, D heavy duty |
| 46 | 3375759 | Overload, 1.6 - 2.5 Amp Mod. D |
| 46 | 3375928 | Overload, OL2 2.7 - 4 Amp Mod. C Stands |
| 50 | 3375760 | Valve, Ball (On/Off) |
| 50 | 3376825 | Repair Kit, Valve Seat (for 3375760 Ball Valve) |
| 51 | 3375761 | Housing, Strainer-Cooler Inlet |
| 52 | 3375762 | Assembly, Strainer Disc |
| 53 | 3375763 | Block, Auxilliary Contact |
| 54 | 3375800 | Filter, Metering Head |
| 55 | 3375801 | By-Pass Tube |
| 56 | 3375802 | Valve, Intake |
| 57 | 3375803 | Valve, Exhaust |
| 57 | 3375478 | Replacement Solenoid Coil (for 3375802 and 3375803) |
| 58 | 3375804 | Valve, Cooler |
| 58 | 3375477 | Replacement Solenoid Coil (for 3375804 (230V)) |
| 58 | 3376043 | Replacement Solenoid Coil (for 3375804 (440V)) |
| Note: 3376621 is a 1/4 NPT 220/240 VAC Solenoid Valve which replaces 3375804 for most North American requirements. |
|
|
| N/A | 3375805 | Lapping Paste |
| 61 | 3375963 | Gear Pump Adapter Kit (Includes 61A, B, C, D and E) |
| 61 | 3375964 | Gear Pump Adapter Kit (Includes 61B, C, D and E) |
| 61A | 3375962 | Gear Pump |
| 61B | N/A | Included in 3375964 Kit |
| 61C | 3375975 | Valve, Pressure Relief |
| 61D | 3376252 | Tube Nut, 10 mm |
| 61E | 3376253 | Tube Sleeve, 10 mm |
| 62 | 3375972 | Assembly, Cooler Tube |
| 64 | 3375976 | Seal, Index Cylinder |
| 65 | 3375977 | Gasket, Index Cylinder |
| 66 | 3375978 | Seal, Index Cylinder |
| 67 | 3375979 | Rod, Index Cylinder |
| 68 | 3376305 | Ring, NH Flanged Inj. |
| 69 | 3376306 | Locator, NH Flanged |
| 70 | 3376307 | Knob, Banjo |
| 71 | 3376313 | Cover, Cam Box |
| 73 | 3376315 | Door Catch |
| 75 | 3376323 | Stirrer Gear Kit |
| Contains: 3376314 and 3376316 (ref. 37) |
|
|
| N/A | 3376971 | Assembly, Stirrer Drive |
| 76 | 3376249 | Indicator, Neon, 220 V |
| 76 | 3376044 | Indicator, Neon, 440 V |
| 77 | 3376251 | Counter, Hours (60 Hz) |
| 78 | 3376469 | Inertia Damper |
| 79 | 3375473 | Fuel Arm Assembly Includes: |
| 80 | 3375474 | O'ring, Nose Piece |
| 81 | 3375475 | Spring, Left Side |
| 83 | 3375968 | Spring, Right Side |
| 84 | 3375969 | Collar, Spring |
| 85 | 3375970 | Housing, Fuel Nozzle Spring |
| 86 | 3375971 | Washer, Dowty |
| 87 | 3375973 | Fitting, Banjo |
| 88 | 3375974 | Bolt, Banjo |
| 89 | 3375664 | O'ring, Nozzle Valve |
| 90 | 3375675 | Valve, Fuel Nozzle |
| 91 | 3375678 | Nylon Washer, Fuel Nozzle |
| 92 | 3375672 | Tappet Assembly |
| N/A | 3376970 | Repair Kit, Tappet |
| 93 | 3375671 | Packing Ring (Datum Valve Rod) |
| 94 | 3375669 | Gasket, Tappet Cover |
| 95 | 3375673 | Fuel Recorder Assembly includes: |
| 96 | 3165099 | Digital Indicator Kit |
| 97 | 3376172 | Deadweight Assembly |
| 98 | 3375797 | O'ring, Deadweight |
| 99 | 3375798 | Gasket, Deadweight |
| 100 | 3375799 | Capscrew, Deadweight |
| 101 | 3376312 | Nut, Nyloc |
| 102 | 3376311 | Washer, Dished |
| 103 | 3376173 | Nose Cone Assembly includes: |
| 104 | 3375471 | Seal, Nylon Nose Cone |
| 105 | 3375472 | O'ring, Nose Cone |
| 106 | 3375795 | Capscrew, Nose Cone |
| 108 | 3375930 | Adjuster Screw, Nose Cone |
| 109 | 3375931 | Dowty Washer, Nose Cone |
| 110 | 3376079 | Ferrule (6 mm) |
| 111 | 3376080 | Tube Nut (6 mm) |
| 112 | 3376171 | Ball and Seat Assembly, Nose Cone |
| 113 | 3376659 | Elbow, Clamp Cylinder |
| 114 | 3376660 | Locknut, Clamp Cylinder |
| 115 | 3376661 | Seal Washer, Clamp Cyl. |
| 116 | 3376664 | Push Button, Orange |
| 117 | 3376667 | Push Button, Red |
| 118 | 3376668 | Push Button, Green |
| 119 | 3376824 | Switch, On-Off |
| 120 | 3376743 | Piston, Fuel Recorder |
| 121 | 3376744 | O'ring and Gasket Kit (Fuel Recorder Ass'y) |
| N/A |
|
|
| Other kits available, not illustrated: |
|
|
| N/A | 3376190 | Cam Nose Cone Ball and Seat Ass'y Kit (Kit Includes: |
| N/A | 3376169 | Cam (.169 Lift) |
| N/A | 3376170 | Cam (.230 Lift) |
| N/A | 3376171 | Ball and Seat Assembly, Nose Cone |
| N/A | 3823360 | Injector Calibration Kit (Kit, K Injectors With 2 Balance Orifices) |
| N/A | 3376862 | Adapter Pot |
| N/A | 3823358 | Cam (.426 Lift) |
| N/A | 3823359 | Anti Splash Shield |
| N/A | 3823963 | Master Injector (200 mm3) |
